Patch Cord SC-UPC SM 3MM 5 Meter

Product Description

1. General Overview

• Product Name: Optical Fiber Patch Cord

• Model Number: SC-UPC-5MTR

• Application: Designed for high-performance fiber optic connections in telecommunications, data centers, and network installations.

• Key Features:

  • SC-UPC connectors for low insertion loss and high return loss.

  • 3mm diameter ruggedized cable for durability.

  • 5-meter length for flexible deployment.

  • Single-mode fiber for long-distance transmission.

2. Optical Specifications

• Fiber Type:

  • Single-mode fiber (SMF-28 or equivalent).

• Wavelength Range:

  • 1260 nm to 1650 nm (Full C, L, and O bands).

• Insertion Loss:

  • 0.3 dB (typical).

  • 0.5 dB (maximum).

• Return Loss:

  • 65 dB (APC polish).

• Polarization Dependent Loss (PDL):

  • 0.1 dB.

3. Connector Specifications

• Connector Type:

  • SC-UPC

• Ferrule Material:

  • Ceramic (zirconia).

• Polish Type:

  • UPC for low back reflection.

• Durability:

  • 500 mating cycles.

4. Cable Specifications

• Cable Type:

  • Simplex fiber optic cable.

• Cable Diameter:

  • 3.0 mm (outer diameter).

• Cable Jacket Material:

  • LSZH (Low Smoke Zero Halogen) or PVC (optional).

• Tensile Strength:

  • 100 N (during installation).

• Crush Resistance:

  • 200 N/cm.

• Bend Radius:

  • 15 mm (minimum, under load).

  • 30 mm (minimum, no load).

5. Environmental Specifications

• Operating Temperature:

  • -20C to +70C.

• Storage Temperature:

  • -40C to +85C.

• Relative Humidity:

  • 5% to 95% (non-condensing).

6. Performance Specifications

• Transmission Distance:

  • Suitable for long-distance transmission (up to 10 km or more, depending on network setup).

• Signal Integrity:

  • High signal integrity with minimal attenuation.

7. Safety and Compliance

• Safety Standards:

  • Compliant with IEC 60825-1 (Laser Safety).

• Environmental Compliance:

  • RoHS compliant (Restriction of Hazardous Substances).

• Flame Rating:

  • LSZH: IEC 60332-1 (Flame Retardant).

8. Ordering Information

• Base Unit: Optical Fiber Patch Cord (SC-APC, 3mm Diameter, 5 Meters).

• Optional Customizations:

  • Custom lengths (e.g., 1m, 10m, 20m).

  • Different connector types (e.g., LC, FC, ST).

  •
